1" Slip DV Series Electric Irrigation Valve
SKU: 4621925
Rain Bird 100DVSS In-Line Sprinkler Valve, 1 Inch, Slip, 0.2 - 40 gpm Flow, Water Media, Plastic Body. Rain Bird manufactures only the highest quality valves. Use DV/DVF series valves in locations where the use of a separate pressure vacuum breaker (PVB) or a double-check valve is required by city codes to protect against back flow. Check your local city codes to determine what type of valves are required.
Energy efficient, low-power encapsulated solenoid with captured plunger and 90-mesh (200 micron) solenoid filter | All of our valves work with any standard sprinkler timer | 0.30 A at 60 hz inrush current | Internal bleed for spray-free manual operation | Double-filtered pilot-flow design for maximum reliability | 24 VAC, 50/60 hz solenoid | Accepts latching solenoid for use with Rain Bird battery operated controllers | External bleed to manually flush system of dirt and debris during installation and system start up | Buna-N diaphragm with self-cleaning 90 mesh (200 micron) pilot water filter and captive spring | 1-1/4 Inch stainless steel phillips head screws | Balanced pressure diaphragm for long life | Operates in low-flow and Xerigation applications when the RBY filter is installed upstream | 0.19 A at 60 hz holding current
Manufacturer Product Page: https://store.rainbird.com/100dvss-1-in-dv-series-inline-plastic-residential-irrigation-valve-slip-x-slip.html | Brochure: https://productcatalog.sheret.com/DocServer/DSAnonDownloadServlet?action=download&type=product-artifacts&key=DS4709d472-75ed-4f51-8ea6-67b48d1fadfb | Brochure: https://productcatalog.sheret.com/DocServer/DSAnonDownloadServlet?action=download&type=product-artifacts&key=DS2c7b6700-aff5-4bda-8e8a-6689a88e9790 | Installation Manual: https://productcatalog.sheret.com/DocServer/DSAnonDownloadServlet?action=download&type=product-artifacts&key=DS873c2227-82fc-4cb0-afb1-c9e339b7eaab | Specification Sheet: https://productcatalog.sheret.com/DocServer/DSAnonDownloadServlet?action=download&type=product-artifacts&key=DSbe8404b1-8a95-426d-94c4-a038fa15b31a | Manufacturer Web Site: http://www.rainbird.com
