24X24 HATCH CVR H20
SKU: 1624200
The H1R (single leaf) and H2R (double leaf) series access frames and covers as manufactured by Halliday Products, Inc. of Orlando, Florida shall have a 1/4 inch (7mm) thick, one-piece, mill finish, extruded aluminum frame, incorporating a continuous concrete anchor. The inside of the frame shall have a door-support ledge on two (2) sides. Both frame and ledge must be supported by a full bed of Class A concrete. The door panels shall be 1/4" (7mm) aluminum diamond plate, reinforced to withstand a live load of the H-20, Uniform live load. Doors shall open to 90 degrees and automatically lock with a T-316 stainless steel hold open arms with release handles. For ease of operation, doors shall incorporate enclosed stainless steel compression spring assists. Doors shall close flush with the frame. Hinges and all fastening hardware shall be T-316 stainless steel. Unit shall lock with a T-316 stainless steel slam lock with removable keys and have a non-corrosive handle. Unit shall carry a lifetime guarantee against defects in material and/or workmanship.
Cover equipped with the following stainless steel features: spring assists, T-316 heavy duty hinges, T-316 tamper proof attaching hardware, automatic T-316 hold open arm with aluminum latch. | Angle Frame: 1/4" (7mm) aluminum with continuous anchor flange. | Guarantee: Access covers shall carry a lifetime guarantee against defects in material and/or workmanship. | Locking System: Type 316 stainless steel slam lock with removable key. | Cover Leaf (s): 1/4" (7mm) aluminum diamond plate. | Load Rating: H-20, Uniform live load.
Manufacturer Web Site: https://www.hallidayproducts.com/index.html | Specification Sheet: https://productcatalog.sheret.com/DocServer/DSAnonDownloadServlet?action=download&type=product-artifacts&key=DS2ce737fc-c211-4615-820e-b6b65903a52a
